NOTES:
1. The height stated is to the top of the unit plus
550mm, which should
allow for a 25mm thick shelf/board
and room for servicing. This
will need to be increased by 125mm if the automatic fill
method is chosen.
2. SP model heated from a heat source at 82.5°C at 16
l/m.
3. Full thermal store volume reheated from 35°C to 75°C.
4. Please refer to the installation manual for the
minimum cupboard space
requirement. This can be reduced
by approximately 70mm if the insulation
is removed
from the plate heat exchangers.
